Two-Way Articulating Borescope C1 Series
Bidirectional 180° articulation | IP67 waterproof & oil-resistant | High-temperature protection | Rechargeable & replaceable battery
C1 Series Industrial Video Borescope
Featuring a high-strength tungsten braided articulation tube, the C1 supports bidirectional 180° steering with precise control. It connects seamlessly to Android, HarmonyOS, and iOS devices for plug-and-play operation. With IP67 waterproof and oil-resistant design, it is ideal for tight spaces and harsh environments. The built-in replaceable battery, real-time temperature monitoring, and automatic shutdown above 90°C ensure safe and reliable performance. Photo, video, and playback functions are all included. Multiple probe diameters are available to meet different inspection needs.
- Bidirectional 180°
- Phone/Tablet Compatible
- Real-time Temp
- Replaceable Battery
- IP67 Waterproof
- >90°C Auto Off
C104
- Probe Diameter: Φ3.9mm
- Bend Radius: 25mm
- Articulation: 180° Bidirectional
- Field of View: 78°
- Depth of Field: Standard
- Effective Pixels: 1280×720 (HD)
- Illumination: 6 high-brightness LEDs (adjustable)
C105
- Probe Diameter: Φ5.5mm
- Bend Radius: 25mm
- Articulation: 180° Bidirectional
- Field of View: 90°±3°
- Depth of Field: Standard
- Effective Pixels: 1280×720 (HD)
- Illumination: 8 high-brightness LEDs (adjustable)
C106
- Probe Diameter: Φ6.2mm
- Bend Radius: 35mm
- Articulation: 180° Bidirectional
- Field of View: 90°±3°
- Depth of Field: Standard
- Effective Pixels: 1280×720 (HD)
- Illumination: 8 high-brightness LEDs (adjustable)
C108S
- Probe Diameter: Φ8.5mm
- Bend Radius: 35mm
- Articulation: 180° Bidirectional
- Field of View: 90°±3°
- Depth of Field: Standard
- Effective Pixels: 1600×1200 (2MP)
- Illumination: 6 high-brightness LEDs (adjustable)
| Parameter | C104 | C105 | C106 | C108S |
|---|---|---|---|---|
| Connection | Supports Android / HarmonyOS / iOS devices | |||
| Menu Language | Simplified Chinese, Traditional Chinese, Japanese, English, Korean, French, Russian, Spanish, German | |||
| Display Functions | Photo / Video / Playback / Image Rotation / Real-time Temperature Display | |||
| TF Storage Card | Supported (up to 128GB) | |||
| Real-time Temperature | On-screen temperature reading | |||
| Articulation Control | Bidirectional 180° joystick control | |||
| Articulation Durability | ≥20,000 cycles | |||
| Insertion Tube Length | 1m / 2m / 3m customizable (standard 1m) | |||
| Insertion Tube Material | Tungsten braided mesh + flexible articulation tube | |||
| Probe Diameter | Φ3.9mm | Φ5.5mm | Φ6.2mm | Φ8.5mm |
| Bend Radius | 25mm | 25mm | 35mm | 35mm |
| Effective Pixels | 1280×720 | 1280×720 | 1280×720 | 1600×1200 |
| Field of View (FOV) | 78° | 90°±3° | 90°±3° | 90°±3° |
| LED Illumination | 6 high-brightness LEDs | 8 high-brightness LEDs | 8 high-brightness LEDs | 6 high-brightness LEDs |
| Waterproof Rating | IP67 (probe and insertion tube waterproof & oil-resistant) | |||
| Overheat Protection | Automatic shutdown above 90°C | |||
| Battery Specification | Rechargeable lithium battery (removable & replaceable) | |||
| Operating Environment | -10°C ~ 50°C, humidity <90%RH | |||
| Certifications | CE, FCC, ROHS, Patented | |||
| Package Dimensions (Box) | 30.2×17.6×6.9cm | |||
| Package Dimensions (Carton) | 55×36.5×33.5cm | |||
Professional Application Scenarios
Industrial Manufacturing & Precision Machinery
Inspect gearbox interiors, mold cavities, and weld quality; quickly detect burrs, cracks, and debris.
Automotive Repair & Inspection
Visually inspect engine cylinders, turbochargers, and transmission systems without unnecessary disassembly.
Pipes & HVAC Systems
Real-time inspection of air conditioning ducts, drainage pipes, and radiators for blockages or corrosion.
Aerospace & Marine
Non-destructive testing of turbine blades, airframe structures, and ship pipelines in tight, curved spaces.
